1.6 CFM Automatic Pneumatic Vacuum System (NU2)
$615.00
1.6 CFM Standard automatic vacuum system
In stock
Product Details
Part Number: NU2
1.6 CFM Automatic Pneumatic Vacuum System – NU-Matic Standard Series
The NU2 is a compact, fully automatic pneumatic vacuum system designed for small-scale veneering, laminating, and vacuum pressing applications. Delivering 1.6 CFM of vacuum flow, this system is ideal for smaller vacuum bags, hobby use, and light-duty shop work.
Powered entirely by compressed air, the NU2 requires no electricity, making it a simple, reliable, and low-maintenance solution. This unit demands 2.0 CFM at 85 PSI, allowing it to operate efficiently on smaller air compressor systems.
The NU-Matic system features an adjustable vacuum sensor that automatically regulates pressure within the vacuum bag or frame press. When vacuum levels drop, the system activates and restores pressure to the desired level, then shuts off once achieved. This automatic cycling eliminates the need for manual monitoring while maintaining consistent vacuum pressure throughout the press cycle.
The vacuum sensor can also be adjusted to reduce pressure when working with delicate materials, giving you greater control over your pressing process.
Key Features
- 1.6 CFM Vacuum Flow: Ideal for small vacuum bags and light-duty applications
- Fully Automatic Operation: Vacuum sensor maintains pressure without manual monitoring
- All Pneumatic System: No electricity required—runs entirely on compressed air
- Low Air Consumption: Efficient operation with minimal compressed air demand
- Adjustable Vacuum Control: Fine-tune pressure for delicate or specialized work
- Simple & Reliable Design: Proven performance with minimal maintenance
- Upgradeable Platform: Easily upgrade to larger NU-Matic systems as your needs grow
Typical Applications
- Small veneering projects
- Laminating applications
- Small vacuum bag pressing
- Hobby and light-duty shop use
Air Requirements
- Air Demand: 2.0 CFM @ 85 PSI
- Compressed air is required for operation
Bottom Line
The NU2 is a simple, automatic vacuum solution for smaller applications. With low air requirements and hands-free operation, it’s an excellent entry point into the NU-Matic system while still delivering consistent, reliable results.
NU-Matic Pneumatic Vacuum System Comparison
| Model | Series | Air Flow (CFM) | Price |
|---|---|---|---|
| NU20 | Mega Industrial | 20.0 CFM | $1,355 |
| NU15 | Super Industrial | 15.0 CFM | $1,290 |
| NU10 | Industrial | 10.0 CFM | $1,092 |
| NU6 | Super-Pro | 5.2 CFM | $835 |
| NU4 | Pro | 3.2 CFM | $705 |
| NU2 | Standard | 1.6 CFM | $605 |
