20 CFM Automatic Pneumatic Vacuum System for Veneering and Laminating (NU20FS)
$1,570.00
20 CFM Mega Industrial ALL-in-ONE automatic vacuum system
In stock
Product Details
Part Number: NU20FS
20.0 CFM Automatic Pneumatic Vacuum System – NU-Matic Mega Industrial Series
The NU20FS is a powerful, fully automatic pneumatic vacuum system designed for high-demand veneering, laminating, and vacuum pressing applications. Delivering 20.0 CFM of vacuum flow, this system is ideal for large vacuum bags, production environments, and heavy-duty shop use where fast evacuation and consistent pressure are essential.
Powered entirely by compressed air, the NU20FS requires no electricity, making it a reliable, low-maintenance solution for professional and industrial settings. This unit demands 26 CFM at 85 PSI, making it best suited for shops with high-capacity air compressor systems.
The NU-Matic system features an adjustable vacuum sensor that automatically regulates pressure within the vacuum bag or frame press. When vacuum levels drop, the system activates and restores pressure to the desired level, then shuts off once achieved. This automatic cycling eliminates the need for manual monitoring while maintaining consistent vacuum pressure throughout the press cycle.
The vacuum sensor can also be adjusted to reduce pressure when working with delicate materials, giving you greater control over your pressing process.
Key Features
• 20.0 CFM Vacuum Flow – Ideal for large vacuum bags and production environments
• Fully Automatic Operation – Maintains vacuum without manual monitoring
• All Pneumatic System – No electricity required
• High Air Capacity – Built for rapid evacuation and large-volume pressing
• Adjustable Vacuum Control – Fine-tune pressure for delicate or specialized work
• Simple & Reliable Design – Minimal maintenance, proven performance
• Upgradeable Platform – Expand within the NU-Matic system lineup
Typical Applications
• Large-scale veneering projects
• Architectural laminating
• Vacuum bag and frame press applications
• Production and industrial shop use
Air Requirements
• Air Demand: 26 CFM @ 85 PSI
• Compressed air is required for operation
Why Use Vacuum Clamping?
• No Surface Damage – Eliminates clamp marks on finished materials
• Unobstructed Tool Access – No bulky clamps interfering with cutting or routing
• Fast Setup – Quickly secure workpieces and increase efficiency
• Even Pressure Distribution – Up to 1,800 lbs/sq. ft. across the entire surface
• Improved Accuracy – Ideal for template routing and precision work
Bottom Line
The NU20FS is a high-performance pneumatic vacuum system built for serious production work. With fast vacuum draw, automatic regulation, and industrial-grade reliability, it delivers consistent, repeatable results for demanding veneering and laminating applications.
